3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

Shenzhen xinhuili Industrial Development Co., Ltd

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

Place of Origin : Guangdong, China

Brand Name : XHL

Certification : GMP

Supply Ability : 10 Set/Sets per Month

Packaging Details : Carton inside , wooden outside , plastic pallet when delivery

MOQ : 1 Set

Price : $19,999.00 - $49,999.00 / Set

Model Number : YGS

Payment Terms : L/C, T/T

Delivery Time : 30 days

Product name : XHL-YGS

Function : Essential balm filling production line

Application : CHEMICAL, pharmaceutical, Biomedicine

Weight : 3000kg

Warranty : 1 YEAR

Filling Accuracy : 99.9%, 99.5%

After-sales Service Provided : Online support, Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service

Warranty of core components : 1 YEAR

Contact Now

XHL-YGS Series Pesticide And Fruit Jam Filling Machine For Plastic Bottle

Product Description

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

Our Factory

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

Our Warehouse

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

Why choose us?

1. 17 years manufacture in filling line and machine
2. 2 years alibaba supplier
3. 100% QC inspection before shipment
4. 12 months warranty
5. Product Certificated by CE, ISO

Overview


The YGS servo- -driven linear liquid fIlling machine uses the 316L stainless steel plunger metering pump to perform filling. According to the actual production capacity of the manufacturer, it can be equipped with different filling heads, and it can conveniently work with the automatic bottle unscrambler and various kinds of cap tumning(capping) machines for linked production. It is widely used for liquid packaging in such industries as medicine, food,chemical industry, pesticide and cosmetics, conforming to GMP requirements.

Main Performance features

- It adopts the plunger moterig pump to perfom filling.With servo driving, the filling volume is adjusted on the man-machine interface.lt is suitable for liquids of various viscosities with high presion. The pump can be easily disassembled, making Cleaning and sterilization convenient. It can be equipped with CIP/SIP cleaningand sterlization system.

- The seal ring of the punger metering pump is made of silicon rnubber, Tefion or other materials depending on different industries and liquid ingredients. Ceramic material can be used in special application. The filling principle also includes the use of peristaltic pump,negative pressure type, weighing type, self-flow type, reflux defoaming type,etc.

the PLC control system with

- The whole line adopts control and high degree ofv ariable frequency speed automation.

- The filling systerm is provided with the ant-leaking device, realizing filling from the bottom of the bottie, rising slowly and avoiding bubbles.

- The whole line is suitable for various specifications of bottle and adjustments can be completed convenienty within a short time.

The whole line is designed acording to GMP requirements.

- Explosion desion can be adopted for products used in special industries or special types of products.

Main Technical parameters

Product model YGS/4 YGS/6 YGS/8 YGS/12 YGS/16 YGS/20 YGS/24
Stable production capacity(taking 100ml for example) 30-50BPM 40-60BPM 60-80BPM 80-100BPM 100-120BPM 120-160BPM 160-200BPM
Filling range 5-5L
Applicable bottle type flat, round, square
Number of filling heads 4 6 8 12 16 20 24
Compressed air 0.4-0.6Mpa
Power 0.75kw 0.75kw 0.75kw 1.2kw 2.2kw 2.2kw 2.2kw
Size 1300*1000*1800mm 1300*1000*1800mm 1600*1000*1800mm 1900*1000*1800mm 2300*1000*1800mm 2300* 1000*1800mm 2600*1000*1800mm
weight 500kg 500kg 800kg 1000kg 1300kg 1500kg 1700kg

Our Partner

3000kg 99.9% Accuracy Water Bottle Filling And Sealing Machine

Our service and warrantee

1.We can customize the machine as customer requried ;
2.Available for OEM/ODM service ;
3.Offer living broadcast or video support;
4.To Door installation and training service ;
5. Offer filling line solution with customer required
6.Customer’s design are welcomed.

We can customize with your packaging materials, production capacity and demands. We will provide you with associated design solutions and case videos.
